8-12665
Kicker Arm (Slingshot) Assembly
..•..
..••
..•..
..•• ..•• ..•• ..•• ..••
.•...
..••
.•...
..••
.•...
..••
.....
..••
.•... .•... .•... .....
.•...
..•.
..••
..•.
.....
.•..
..••
.•..
.....
...•
.•...
.....
.....
.•...
.•...
..••
Associated Parts for Right & Left Kickers
Item Part Number
Description
Item Part Number
Description
1.
12-6227
Hairpin Clip
6.
A-14369-R
Coli & Bracket Assy. Right
2.
A-12664
Kicker Crank Assembly
A-15749
Coli & Bracket Assy, Left
3.
A-S653
Mounting Bracket Assembly
a) 8-7572-1
Bracket & Stop Assembly
4.
4700-00030-00 Flatwasher,
17/64
x
112
x 15ga.
b)
01-8-508-5
Coil Retaining Bracket
5.
A-51 03
Coli Plunger Assembly
cJ 4006-01017-06
Mach. Screw, 6-32 x
3/8
a) 02-2364
Coil Plunger
d) 4406-01119-00
Nut, 6-32 ESN
b) 03-8085
Armature Link
e) AE-27-1200
Coil Assembly
cJ 20-8716-5
Roll Pin,
1/8
x
7116"
f) 03-7066
Coil Tubing
7.
10-128
Spring
FISH TALES 2·21
