Cabinet Parts
Item Part Number
Description
Item Part Number
Description
1.
0·9174·3
Lever Guide Assembly
12. 0-12615
Front Molding Assy.
2.
A·14148·1
Coin Door- 2 Slot
13. 20-6502-A Plum Bob
3.
A-15130
Fishing Reel Handle Assembly
14. A-12359-3
Side Molding Assembly
4.
8-12273-4
Flipper Bulton - Red (2 Used)
15. 20-9663-1
Start Button
5. A-15579-1
Cashbox Assembly
16. A-15894
Flipper Opto Board
6.
'"
Line Filter Assembly
17. 01-10714
Line Cord Cover
7.
5610-12835-00 WPC Transformer,
1151230v
18.
11-1067-50005
Fish Tales
Wood Cabinet
8.
5555-12929-00 Speaker,
4f!,
6", 25w
19.
'"
Cordset
9. 20-9347
Toggle Latch
10.
A-14689
WPC Coin Door Interface Bd.
11. C-10843
Metal Leg Assembly
'" See Application Chart.
line Filter/Cordset Application Chart
COUNTRY
UNITED STATES
CANADA
•
•
FISH TALES 2-2
