6. Extend each leg leveler
slightly
below the leg bottom, so that all four foot pads are extended about the
same distance.
Remove the cabinet from its support and place it on the floor.
7. Unlock and open the coin door. Move the molding latch lever toward the left side of the game. Lift the
front molding off the playfield cover glass return the latch lever toward the right, and close the coin door.
Carefully slide the glass downward, until it clears the grooves of the left and right side moldings. Lift the
glass up and away from the game.
8. Place a level or an inclinometer on the playfield surtace. Adjust the leg levelers for proper playfield level
(side-to-sloe).
Note:
It is recommended that this measurement be made ON the playfield, not the
cabinet nor the playfield cover glass. Tighten the nut on each leg leveler shaft to maintain this setting.
_.
The Tru-Pitch™ level is located on the shooter rail. This allows the operator to accurately pitch the game -
without removing the glass - when it is first set in a new location. The first line on the level is approximately
6 degrees. Every line after that is approximately another
1/2
degree of pitch. We recommend you pitch
the game with the nose of the bubble between the first and second line on the level (between 6 and 6-1/2
degrees).
! IMPORTANT!
Playfield pitch angle can affect the operation of the plumb bob tilt. The plumb bob weight is among the
parts in the cash box; the operator should install the weight after setting the desired playfield pitch angle.
9. Install the Fishing Reel handle mechanism. Lift the playfield. Place the Fishing Reel handle into the
hole in the cabinet (where the plunger is normally located). From the front of the cabinet, slide a washer
and a cap head screw through each of the four holes. From the inside of the cabinet, Slide a washer over
each of the four screws. Secure into place with an ESNA nut. Plug the handle cable into the cabinet
cable. Be sure the wire colors match on both connectors. lower the playfield.
To il"lstall 10-32 ESN Nut
lise
318"
Nut Driver (Color Code: Blue)
NutlO-32ESN~.,~
Flat Washer -
'J-s
Flat Washer
G-....
I
'c,
1' .
,
....•.
[
......•
I
.
I
I
FISH TALES 1·3
