515
TYPICAL
PLAYFIELD PLAYFIELD PLAYFIELD PLAYFIELD PLAYFIELD NOT USED NOT USED
4A
Playfield Switch Wiring Diagram
Switch
No. FunctIOn
1 Plumb Till
2 Ball Roll Tilt
3 Credit Button
4 Right Coin
5 Center Coin
6 left Coin
7 SlamTill
8
High Score Reset
9 Outhole
10 Right Ball Ramp
11 left Ball Ramp
12 Ball shooter Trough
13 lane Change
14 Ramp In Roll Under
15 Ramp out Roll Under
16 Center left Standup
17 Siandup
18 Spinner
19 Orbit In Roll Under
20 Upper left Siandup
21 Nol Used
22 Upper Right Standup
23 Eject Hole
24 Release Target
25 "F"Target
26
"r
Target
27 "R"Target
28 "E"Target
29 "P"Target
30 "0" Target
31
"W"
Target
32 "E"Targel
33 "R"Target
34
"A"
Rollover
35 "B"Rollover
36 "C" Rollover
37
"D"
Rollover
38 left Oullane
39 Right Oullane
40 Orbit Out Gale
41 lower left Jet Bumper
42 Upper Right Jel Bumper
43 Upper left Jet Bumper
44 lower Right Jet Bumper
45 left Flipper Return lane
46 Right Flipper Relurn lane
47 left Kicker
48 Right Kicker
49 Playfield Till
50 Nol Used
51 Not Used
52 Not Used
53 Not Used
54 Not Used
55 Nol Used
56 Not Used
57 Nol Used
58 Not Used
59 Not Used
60 Not Used
61 Not Used
62 Not Used
63 Not Used
64 Not Used
NOTE:Second value scored when III
•
(Score)
(100)
(100)
(100/1000)
(50)
(50)
(5000/lll Value)
(1000)
(1000)
(1000)
(1000)
(1000)
(1000)
(1000)
(1000)
(1000)
(1000)
(1000)
(1000)
(1000)
(1000)
(10,000)
(10,000)
(100/1000)
(100/1000)
(100/1000)
(100/1000)
(1000)
(1000)
(10)
(10)
•
•
