TYPICAL
LUMN
Lamp
•
No.
=~.'}
1
2 Match
Backbox
3 Tilt
4 High Score
Lamps
5 Shoot Again
6 Shoot Again
7 Double Score
8 Bonus Holdover
9 1,000 Bonus
10 2,000 Bonus
11 3,000 Bonus
12 4,000 Bonus
13 5,000 Bonus
14 6,000 Bonus
15 7,000 Bonus
16 8,000 Bonus
17 9,000 Bonus
18 10,000 Bonus
19 20,000 Bonus
20 40,000 Bonus
21 60,000 Bonus
22 80,000 Bonus
23 Bonus Holdover
24 Fire Power Special
25 'F"
26 '1"
27 'R'
28 'E"
29 'P'
30 '0"
31
'W
32 'E"
•
33 'R"
34 'A"
35 'B"
36 'C"
37 '0"
38 Left Drain Special
39 Right Drain Special
40 Bailin Play
41 Lower Left Jet Bumper
42 Upper Right Jet Bumper
43 Upper Left Jet Bumper
44
Lower Right Jet Bumper
45 Left Flipper Return Lane
46 Right Flipper Return Lane
47 Mystery
48 Exira Bali
49 2x
50 3x
51 5x
52 Eject Hole 10K
53 Eject Hole 20K
54 Eject Hole SDK
55 Eject Hole Lock Arrow
56 Release Target SDK
57 Release Target 100K
58 Release Target 150K
59 Release Arrow
60 Spinner
61 Not Used
62 Not Used
63 Not Used
64 Not Used
•
64
LAYFIELD PLAYFIELD PLAYFIElO NOT USED BACKBOX PLAYFIELD NOT USED
OARD WIRING DIAGRAM FOR CONNECTIONS FOR BACKBOX LAMPS •.
42
Playfield Lamp Wiring Diagram
