Figure
5.
Solenoid Locations
•
SOLENOID TEST
1. From lamp Test depress ADVANCEwith the switch
set to AUTO-UP.Test 02 should be indicated in the
Credits display. The Match display sequences
from 01 thru 25. Corresponding solenoids 01 thru
24 are pulsed. Flipper relationship Is de-energized
with subtest 25.
2. To continuously pulse a single solenoid set switch
to MANUAL-DOWN .Operate ADVANCEpushbutton
to sequence through the solenoids one at a time .
Set switch to AUTO-UPto resume sequencing.
SOl.
No.
Function
1 Outhole
2 Ball Ramp Thrower
3 Eject Hole
4 Orbit Complete Flash lamps
5 Not Used
6 Not Used
7 Not Used
8 Not Used
9 Not Used
10 Not Used
11 Generall Illumination Relay
12 Not Used
13 Not Used
14 Not Used
15 Bell
16 Coin lockout
17 left Kicker
18 Right Kicker
19 lower left Jet Bumper
20 Upper Right Jet Bumper
21 Upper left Jet Bumper
22 lower Right Jet Bumper
19
