Page 10 - Firepower II

•
•
•
Table 3. Standard and Custom Price Settings
COIN DOOR FUNCTION
MECHANISM CREDITS 19 20 21 22 23 24 25
Twin-Quarter 1/2S¢, 3/S0¢, 7/$1 00 03 12 03 02 12 00
Quarter, Dollar, Quarter 1/2S¢, 3/S0¢, 7/$1 coin only 00 03 14 03 02 00 00
1/2S¢, 7/$1 coin only 00 01 07 01 01 00 00
1/2S¢, 3/S0¢, 6/$1 00 01 04 01 01 02 00
1/2S¢, 6/$1 coin only 00 01 06 01 01 00 00
1/2S¢, S/$1 00 01 04 01 01 04 00
2/S0¢, S/$1 00 01 04 01 01 04 02
1/2S¢, S/$1 coin only 00 01 OS 01 01 00 00
·1/25¢, 41$1 01 01 04 01 01 00 00
2/S0¢,4/$1 00 01 04 01 01 00 02
·1/50¢, 2/75¢, 3/4 x 25¢ 05 03 15 03 04 15 00
4/$1 or 5 x 25¢
1/S0¢, 3/$1, 4/$1.2S 00 03 12 03 04 is 00
1/50¢, 3/$1, 7/$2 00 12 48 12 14 96 18
-1/50¢, 3/$1, 6/$2 03 01 04 01 02 04 00
1/50¢ 00 01 04 01 02 00 00
10M. 5DM. 20M -1/1DM,3/2DM, 10f5DM 02 09 45 18 05 45 00
2/1DM 5/2DM, 14/5DM 00 13 65 26 05 65 00
20-Cent SO-Cent 1/20¢, 3/50¢ 00 06 00 15 05 00 00
1 Franc 10 Franc, 5 Franc -1/2. 3/5F only.8/10Fonly 04 01 16 06 02 00 00
25 Cent, -1/25¢, 4f1G 06 01 00 04 01 00 00
1 Guilder 1/25¢ 5/1G 00 01 00 04 01 04 00
Twin 100 Yen 2I100Y 00 02 00 02 01 00 00
1 Franc or 1/1F,3/2F 00 01 01 01 01 02 00
Twin-1 Franc 1/1F 00 01 01 01 01 00 00
5 Franc, ·1/5F, 2/10F 07 01 00 02 01 00 00
10 Franc ·1/10F 08 01 00 02 02 00 00
Twln-2 Franc ·1/2F 03 01 04 01 01 00 00
10 20 Franc ·1/10F 2/20F 07 01 00 02 01 00 00
Twln-1 5ucre 1/35, 2/55 00 02 00 02 05 00 00
·Indicates standard price settings by adjusting only Function 19. For other price settings, set Function 19 to 00 and set
Functions 20 through 25 to the values indicated in the chart .
13
