7.
#926 - "FIRE BALL"
GAME ADJUSTMENTS
PLAYFIELD PANEL POST ADJUSTMENTS:
Posts that control left and right outlane opening on panel (see
panel sketch FO-320) can be moved to make access to outlanes
easier or harder for ball to enter.
Easier entry will "decrease" playing time and scoring.
Harder entry will
II
increase
II
playing time and scoring.
BELL ADJUSTMENT PLUG:
Located on back box lite insert. This plug provides positions
to ring bell for "100" point scores, "1000" point scores, or
both 11100
&
1000" point scores.
HI-SCORE ADJUSTMENT PLUG:
Located on back box lite insert. This plug provides a wide range
of coverage at which hi-score "credits" can be scored. (see
"Score adjustment card" in back box for plug positions).
(
MATCH FEATURE ADJUSTMENT PLUG:
Located on front cabinet mounting board. This plug provides
positions to operate game on "5th ball" or "3 ball" play.
HI-SCORE FEATURE ADJUSTMENT PLUG:
Located on front cabinet mounting board. _This plug provides
positions to turn hi-score "credit" feature "on" or "off".
1ST COIN CHUTE ADJUSTMENT PLUG
Located on the 2 coin unit, on front cabinet mounting board.
This plug provides positions to give "1 play for 1 coin" or
III
play for 2 coins
II
thru the 1st (nickel) coin chute.
2ND COIN CHUTE ADJUSTMENT PLUG:
Located on front cabinet mounting board. This plug provides
positions to give "1 play for 1 coin" or "2 plays for 1 coin"
thru the 2nd (dime) coin chute. Note: When this plug is set
for 112plays - 1 coin
II,
brown-white (male plug) wire on 3rd
coin chute adjustment must be in "position 2".
3RD COIN CHUTE ADJUSTMENT PLUG:
Located on front cabinet mounting board. This plug provides
positions to give "2 to 6 plays for 1 coin" thru the 3rd
(quarter) coin chute. Use orange-white (male plug) wire.
