6803 Pinball Power Module w/Fuses
A084-91785-AB38
Squawk & Talk
A084-91625-AB38 AS-2518-61
6-Digit Display Driver (1 used) .............................•........
A084-91491-AOOO AS-2518-21
7-Digit Display Driver (4 used)
A084-91617-AOOO AS-2S18-58
6803 Pinball Control Module
,
A084-91786-AB38
XIII. ABBREVIATED PARTS LIST (cont'd)
EIGHT BALL CHAMP
ASSEMBLY COILS
MIDWAY
PART
NUMBER
Flipper (3)
"
"
" A360-0004S-0000
Knocker. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. A360-00046-0000
Outhole Kicker .... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. A360-00044-0000
Thumper Bumper (2)
A360-00044-0000
Saucer
" A360-00211-0000
Sling Shot (2)
A967-00046-0000
Drop Target (5)
AB38-00018-0000
PLAYFIELD PARTS
See Figure II
Playfield Glass
0360-00921-0000
Playfield
&
Inserts
AB38-00501-00XF
Roll-over Button - White (3)
0017-00042-0405
Button: Roll-over Mounting - Green (2)
0017-00042-0541
Button: Roll-over Mounting - Amber. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 0017-00042-0544
Playfield Mylar
OB38-00901-0000
Screened Plastic Set
,
"
"
AB38-00012-00XF
Post: L=1" Red Plastic (10)
0017-00042-0588
Post: L=1-3/16" Red Plastic (26)
0017-00042-0596
Acorn Nut: Nylon (19)
0017-00009-0302
Thumper Bumper Cap
&
Tape Assembly (2)
,
AB38-00011-0000
Collar-Thumper
Bumper - Red (2)
0017-00042-0566
Thumper Bumper Locking Ring (2)
0017-00042-0414
Thumper Bumper Mylar (2)
OB38-00911-0000
Flipper - White (3)
A967-00031-0000
I
r
MODULES
MODULE COMPONENTS
SEE MODULE PARTS LIST
1-24
BALLY
PART
NUMBER
AQ-25-500/
. 34-4500
AR-26-1200
AN-26-1200
AN-26-1200
AO-27-1300
AO-26-1200
G-409
C-900
C-901-4
C-901-8
M-1794-1
C-1018-1
A-3994-5
