Backbox Assembly
111114---1
24
Item Part Number
Description
Item Part Number
Description
1.
01-6645
Venting Screen
16.
A-15309-1
2-10W Resistor Board
2.
B-l0686-1
Knocker & Bracket Assy.
17.
A-16199
Dalek Assembly
3.
A-12497
Upper Insert Bd Hinge Assy.
18.
A-16191
Dalek Light Assembly
4.
A-14092-3
Mounting Plate Assembly
19.
A-15742
4-Lamp Board
5.
A-12498
Lower Insert Bd Hinge Assy.
20.
A-15748
Cover Assembly
6.
A-12697-1
Power Driver Assembly
7.
A-12738-20006
WPC Sound Board
Ribbon Cables:
8.
A-12742-20006
WPC CPU Board
9.
A-14376-20006
Backbox Assembly
21.
5795-12653-03
Ribbon Cable, 3"
10.
01-9047
Insert Stop Bracket
22.
5795-13018-00
Ribbon Cable, 22"
11.
A-15823
Speaker / Display Assy.
23.
5795-10938-14
Ribbon Cable, 14"
a)
5555-12924-00
Speaker, 40, 15w
24.
5795-12838-30
Ribbon Cable, 30"
b)
5555-12856-00
Speaker, 5-1/4", 40, 25w
c)
5045-12914-00
Cap., 10J.lfd., 50v, (±20%)
Miscellaneous Parts:
d)
5901-12784-00
Dot Matrix Display/Driver Bd.
e)
A-15805
7-Lamp Board Assembly
A-8552-20006
Tempered Backglass Assy.
12.
A-14039
Dot Matrix Con toller Board
08-7456
Backbox Glass: 27" x 18-7/8"
13.
A-13379
Lock & Plate Assembly
31-1~57-20006
Screened Translight
a)
20-9637
Lock & Cam Kit
03-8228-2
Glass Channel Top (1)
14.
20006-IN
Insert Board
03-8228-3
Glass Channel Edge (2)
15.
A-15472
Fliptronic II Board
03-8229-1
Glass Lilt Channel (1)
