T.6 General Illumination
This test checks all of the General Illuminationcircuits. There are two modes of operation: Stop and
Run.
Stop
Press the Up or Down buttons to cycle through the General Illumination Test manually.
All illumination is tested first, followed by an individual circuit test. The circuit name and
number will show in the display while the corresponding lamps light. If any other results
occur the system has detected an error.
Run
Press the Enter button any time during Stop test mode and the General Illumination
Test cycles through automatically. For each circuit shown in the displays the
corresponding bulbs should light. If any other results occurs the system has detected
a problem.
T.7 Sound and Music Test
The Sound and Music Test allows you to check the
audio circuits. This test has three modes for testing the sound and music circuits: Run, Repeat,
and Stop.
Run
This Run mode steps through a sequence of sounds and music. Pressing the Up or
Down button during this portion of the Sound and Music test advances to a particular
sound/tune without having to wait for the program to play all the sounds available in the
test. A sound/tune should be heard for each name and number that appears in the
display. Any other results indicate the system has detected a problem.
Repeat
Press the Enter button at any time during the Run mode to cause the program to stop
and repeat a particular sound/tune. The same sound should repeat continuously until
the Up or Down button is pressed. Any other results indicates the system has
detected a problem.
Stop
Press the Enter button at any time during the Repeat mode to stop this test altogether.
No sound/tune should be heard. Any other results indicates the system has detected
a problem.
T.8 Single Lamp Test
The number assigned to each lamp indicates the lamp's
position in the matrix. The number on the left indicates the column. The number on the right
indicates the row. Example: Lamp 23 means 2nd column, 3m row.
This test checks each lamp circuit individually. Press the Up or Down button to cycle through
this test. For each name and number that is shown in the display the corresponding lamp
should light. Any other results indicate the system has detected a problem.
T.9 All Lamps Test
This test causes all the controlled lamps to flash at the same time.
Every controlled lamp should flash. Any other results indicate the system has detected a
problem.
T. 1
0 Lamp and Flasher Test
This test causes all the flashlamps and the controlled
lamps to flash at the same time. The controlled lamps blink, while the flashlamps cycle from
highest to lowest. Any other results indicates the system has detected a problem.
DOCTOR WHO 1-17
