Opto Switch 10 PCB Assembly
A-15430
<0
0
[Ir
*
0
CD
0
..,
C-
o
..•
0
I.()
0
0
...•.
0
[lr
1.1)
..,
<0
0
I.()
0
*
C-
r:
0
..,
0
0
.,
..,
0
J3
...•.
0
I.()
0000000*0000
12
1
J4-1 Gray, to opto transmitter Sw #33
J4-2 Key
J4-3 Black, to opto transmitter Sw #33
J4-4 White, to opto receiver Sw #33
J4-5 Green, to opto receiver Sw #33
J1-1 Gray-Violet, to opto transmitter Sw #77
J1-2 Gray-Blue, to opto transmitter Sw #76
J1-3 Gray-Green, to opto transmitter Sw #71
J1-4 Gray-Yellow, to opto transmitter Sw #72
J1-5 Gray-Orange, to opto transmitter Sw #73
J1-6 Gray-Red, to opto transmitter Sw #74
J1-7 Gray-Brown, to opto transmitter Sw #75
J1-8 Key
J1-9 Black, Ground
J5-1 Gray-Yellow, to opto transmitter Sw #32
J5-2 Black, to opto transmitter Sw #32
J5-3 Key
J5-4 White, to opto receiver Sw #32
J5-5 Green, to opto receiver Sw #32
J2-1 Orange-Violet, to opto receiver Sw #77
J2-2 Orange-Blue, to opto receiver Sw #76
J2-3 Orange-Green, to opto receiver Sw #71
J2-4 Orange-Yellow, to opto receiver Sw #72
J2-5 Orange-Black, to opto receiver Sw #73
J2-6 Key
J2-7 Orange-Red, to opto receiver Sw
#l4
J2-8 Orange-Brown, to opto receiver Sw #75
J2-9 Gray, +12VDC
J6-1 Gray, to opto transmitter Sw #31
J6-2 Black, to opto transmitter Sw #31
J6-3 White, to opto receiver Sw #31
J6-4 Key
J6-5 Green, to opto receiver Sw #31
J3-1 Black, Ground
J3-2 Gray-Yellow, +12VDC from J118-2
J3-3 Green-Orange, from J206-3, to playfield switches
J3-4 Green-Violet, from J206-7, to playfield switches
J3-5 Key
J3-6 White-Violet, from J208-8, to playfield switches
J3-7 White-Blue, from J208-7, to playfield switches
J3-8 White-Green, from J208-5, to playfieJd switches
J3-9 White-Yellow, from J208-4, to playfield switches
J3-10 White-Orange, from J208-3, to playfield switches
J3-11 White-Red, from J208-2, to playfield switches
J3-12 White-Brown, from J208-1, to playfield switches
DOCTOR WHO 3-12
