Flipper Opto Switch Board
A-15894
Left Side Flipper Opto Switch Board
J1 - 1 Blue-Gray (lower flipper) from Fliptronic
II
Board J905-2
J1 - 2 Black-Blue (upper flipper) from Fliptronic
II
Board J905-5
J1 - 3 Orange (Switch Grd) from Fliptronic
II
Board J905-6
J1 - 4 Orange (Switch Grd) loop from J1-3
J1 - 5 Key
J1 - 6 Gray-Yellow (+12V) from Power Driver Board J116-2
J1 -
7
Gray-Yellow (+12V) loop from J1-6
Right Side Flipper Opto Switch Board
J1 - 1 Blue-Violet (lower flipper) from Fliptronic
II
Board J905-1
J1 - 2 Black-Yellow (upper flipper) from Fliptronic
II
Board J905-3
J1 - 3 Orange ((Switch Grd) loop from Left Side Opto Board J1-4
J1 - 4
N/C
J1 -
5
Key
J1 - 6 Gray-Yellow (+12V) from Power Driver Board J116-2
J1 - 7 Gray-Yellow (+12V) loop from J1-6
Please Note:
The Left Flipper Opto Switch Board must be
connected In order for the Right Flipper Opto
Switch Board to operate because power and
gound are connected though the printed
circuit board.
FLIPTRONIC II FLIPPER END-OF-STROKE SWITCHES
Jl
,----_..CJ.I.:.<'-t2
-J..U<Z---i
5
, Fllptronlc
II
Board
+12V
, Fllj;t':;'.;icil B~ard:
,
J906,
1~~~~~~~~'~--,
,
4 ,(U6A-5) Black-Violet F5
r - - - - - - - - - - - - - - - - - - - - - - I
+5V
,
J906,
End-of-5troke Switch
1N4004 : Black-xxx
'J
I-----<.__-=--''''-I-;-;-;-;~-.!-__l~__l
X ,
0
,
: Orange
Dedicated Input
5 '(U6C-9) Black-Gra
I
•
.J
SWitch
F1 lower Right Flipper
F5 Upper Right Flipper
B
,
-
_ _ _ _ _ _ _ _ .J
A
H
l
H
l On
F3 lower le« Flipper
F7 Upper le« Flipper
Open
Closed
The flipper switch circuits operate similar to the dedicated switch circuit. The circuits are active low and tied to ground
through the switch,
When a switch closes the row side (dedicated input) of the circuit activates, The "+" input to the LM339 drops below +5V
causing its output to go low. Since the row (dedicated input) circuit is tied directly to ground through the switch, the switch
is considered closed by the microprocessor,
When the switch opens, the "+" input to the LM339 is above +5V, its output
is high and the row (dedicated input) is inactive.
DOCTOR WHO 3-9
