Item Part
Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
01-10682
20-9734-6
A-15438-L
B-8284-1
01-10683
20-9250-6
01-10688
01-10689
A-15444
A-15631-4
A-12121
01-10690
01-10691
02-4657-2
01-10644-L
01-10671
01-10646-L
02-4657-1
02-4252-10
A-8112-L
B-9414-3
03-8254-9
01-10646-R
01-10644-R
A-15903
02-4436-2
01-10687
01-10685
01-10686
01-10673
A-15719
A-15904
A-15862
02-4436-13
A-12258-2
A-15647
A-15439
A-15438-R
A-15802
01-10684
A-15720
A-8039-3
UPPER PLAYFIELD PARTS LIST
Description
Ball Guide
Flipper Bat and Shaft (2)
Flipper Ball Guide
Kicker Count Switch
Ball Guide
Flipper Bat and Shaft
Ball Guide
Ball Guide
Gate Assembly
Stand-up Target w/Decal
Ball Deflector
Ball Guide
Ball Guide
Stand-off 3"
Ball Guide
Ball Guide (2)
Deflector Bracket
Stand-off 3 1/4"
Stand-off 5/8"
Ball Gate Assembly
Jet Bumper Assembly
Jet Bumper Cap, Red
Deflector Bracket
Ball Guide
Stand-up Target w/Decal
Stand-off 2.31"
Ball Guide
Ball Guide
Ball Guide
Ball Deflect Bracket
Shooter Gate Assembly
Switch Gate & Decal
Stand-up Target w/Decal
Stand-off 2 1/8"
8-32 Nut Plate Assembly
Tardis Assembly
6 Target Assembly
Flipper Ball Guide
Level Assembly
Ball Guide
Kicker Bracket Assembly
Ball Release Assembly
Not Shown:
A-13204-2006
A-15691
A-8645
B-8623
C-8235
01-3569-1
01-5575
01-8419
01-10136
03-7960-20006-2
03-7960-20006-3
03-7960-20006-4
03-7960-20006-5
12-6542
20-6500
36-20006
36-20006-1
31-1681-1 th ru 18
Bottom Arch Assembly
Mini-playfield Cover/Side
Wire Form & Bracket
Guide & Baffle Assy.
Ball Runway Assy.
Ball Return Runway
Bottom Arch Mtg. Brkt. (2)
Holdown Bracket (2)
Shooter Cover Plate
Jet Area Mylar
Drop Area Mylar
Oval Mylar
Mini-playfield Mylar
Runway Gate Wire
1 1/16 Steel Ball (3)
*Screened Playfield
Screened Mini-playfield
Playfield Plastics
* The DOCTOR WHO Diamond Plate™
playfield does not require a full mylar.
However, mylars can be purchased
through your local Bally Distributor (ref.
#03-7960-20006-1 ).
DOCTOR WHO
2-42
