Universal Power Interface Assembly
SIDE VIEW
____1_
I.Wn part
Number
pescrlptlon
IWn part
Number
pescrlptlon
1.
01-12293
Power Control Chassis Box
15.
20-9682-1
Boot w19-32 Dia. Hole
2.
4406-01128-00
Nut #6-32 KEPS
16.
5102-13864-00
Une Filter wllEC Connector
3.
01-12294
Switch Mounting Plate Assy.
17.
01-12292
Une Filter Chassis Box
4.
5642-13935-00
Power Switch
18.
H-17992
Jumper Cable Neutral Sw/1 FC
5.
01-12299
Insulator, Terminal Strip
19.
4004-01003-05
Mach. Screw, #4-40 x 5/16 P-PH-S
6.
RM-21-06
#18 Vinyl Fgls
20.
H-18050
Jumper Cable, Transformer Prog.
7.
5822-13865-00
Terminal Strip 3-CKT 2-Mtg.
21.
16-9667
Label Convenience Rcpt. Rating
8.
5733-12869-00
Fuse Holder Panel
22.
H-17543
Hot Jumper Black Cable
9.
4408-01128-00
Nut #8-32 KEPS
23.
H-17546
Jumper Interface Hot Black Cable
10.
5851-13867-00
Oudet-IEC Conn. 237 Socket
24.
H-17545
Jumper Switch/Fuse Black Cable
11.
03-8712
Strain Relief Bushing
25.
H-17542
Ground Jumper
12.
5016-12978-00
Thermistor SA., 2.5R25
26.
5797-13940-01
Jumper Cable
13.
4008-01017-10
Mach. Screw, 8-32 x 518 P-PH·S
27.
01-10623
Insulator, Thermistor
14.
03-7520-3
Ty-Wrap Nylon
DEMOLITION MAN
2-33
SIDE VIEW
0
0
0
U~I
C
[i]~g
0
0
0
0
0
TOP VIEW
