A·17241
Ramp Diverter Assembly
o
o
o
5
~------------------~--I------
I
.IWn
part
Number
Description
1.
01-11957
2.
A-l0B21
3.
01-7695
4.
20-8790
5.
FL-11753-1
6.
4006-01017-04
7.
4010-01066-06
8.
4701-0004-00
9.
03-7066-5
10. A-16636
11. 10-303
12. A-14185
13. 4010-01169-04
Mounting Bracket
Flipper Stop Bracket
Solenoid Bracket
Nyliner Bearing
Flipper Coil Assembly, Yellow
Mach. Screw, 6-32 x
1/4
P-RHD SEMS
Mach. Screw, 10-32 x 318SHD CAP
Lockwasher #10 Spl~
Coil Tubing
Diverter Plunger Assembly
Spring
Drive Arm Assembly
Set Screw, 10-32 x
1/4
SH CP-IN
• Associated Parts:
part
Number
Description
A-18242
Ball Guide Diverter Assembly
DEMOLITION MAN 2-31
