A-17829-1
Hmn
part
Number
1.
11-831-50028-1
2.
A-17597
3.
A-16989
4.
C-13337
5.
A-18201
6.
03-6047-2
7.
03-7655-4
8.
01-12569
9.
4408-01118-00
10.
4008-01113-08
11.
4808-01175"()7Y
12.
4808-01175-08
13.
4106-01115-16
14.
H-18086
15.
4008-01168-12
Backpanel Assembly
Description
Back Panel - Wood
Elevator Assembly (see below for parts listing)
Cryoclaw Assembly (see page 2-26)
Single Flashlamp Assembly
Socket & #44 Bulb Assembly
Spacer 318"
Clamp Cable. 1/4"
Gusset Bracket
Nut 8-32 Tee 318"
Mach. Screw, 8-32 x
1/2"
E-P #8
x
7/16
E-P #8 x
1/2
Sh. Metal Screw, #6
xl"
Backpanel Cable
Mach. Screw" 8-32 x 314"
A-17597 Elevator Assembly
Hmn
part
Nymber
Description
1.
A-16909
Opto LED Assembly RTV
2.
A-16908
Opto Photo Transistor, RTV
3.
4106-01013-06
Sh. Metal Screw, #6 x
318'
4.
A-17582
Opto Shield & Bracket Assembly
5.
20-8712-25
"E"-Ring •. 210" Shaft
6.
20-9610
Bearing - Flange
7.
03-9023
Spacer. Bearing
8.
12-6227
Hairpin Clip
9.
4700-00103-00
Flatwasher,
1/2
x
17/64
x 28ga.
10.
4008-01003-08
Mach. Screw, 8-32 x
1/2"
11.
02-4926
Elevator Guide Shaft
12.
A-17610
Drive Link Assembly
13.
4010-01169-04
Set screw, 10-32 x
1/4"
14.
A-17335
Drive Arm Assembly
15.
14-7993
Gearmotor
16.
A-17228
Elevator Frame
17.
01-11785
Elevator Mounting Plate
18.
4008-01003-05
Mach. Screw, 8-32 x 5/16
19.
A-17596
Opto PCB Assembly
20.
4404-01119-00
Nut 4-40 ESN
21.
4004-01003-05
Mach. Screw. 4-40 x 5/16
22.
H-16960
Crane Motor Cable
23.
H-17609-08
Opto Cable - Square
DEMOLITION
MAN
2-24
