Flipper Assembly
A~15849~L·2 (Shown)
(lower left Flipper)
A~15849~R~2
(lower Right Flipper)
A·14876-L
(Upper-left Flipper)
'" ..•.
,
..•.
,
..•. ..•. ..•.
'" ..•.
..•.
,
..•.
'"
..•.
...
.•...
..•.
..•.I
~
• Flipper Notes:
1. Each Flipper Assembly is moumed beN!ath the playfield. in conjuction with the Plastic Flipper
&
Shaft. and Flipper Rubber
on the upper side of the playfield.
2. With the flipper, in the non-activated position, the E.O.s. Switch contacts must have a gap of .062 (±.015) inch. When
/lip per is activated switch must close.
3. Any adjustment of the E.O.s. Switch must be made at a minimum distance of 0.25 inchfrom the switch body.
4. Longer blade of E.O.S. Switch must be straight. Gap adjustment is doN! by adjusting shorter blade.
5. All moving elements of the assembly must operate freely without any evidence of binding.
6. Apply Loctite'DI245 when reataching screws to the Flipper Stop Assembly. the Solenoid Brackel. and the Flipper Bushing.
