IMPORTANT NOTICE
PLEASE READ
Pinball games are now equipped with a SAFETY FEATURE to prevent shocks
from the solenoid circuit when the eoln door is opened. A new interlock switch
assembly (part no. A-18249), located at the left of the coin door opening, has
been added to the game. This assembly isa bracket containing the existing
memory protect switch on the bottom and a new interlock switch on the top.
When the coin door Is opened, this new Interlock switch opens, breaking the
connection to the +50V and +20V winding of the transformer secondary.
A special tool called the Service Switch Actuator Is provided for the
servi·ceman/technician that repairs the game. This tool is painted yellow and
located in a bag stapled inside the cabinet. The Service Switch Actuator slips
over the interlock switch and holds It closed while the coin door Is opened,
allowing the serviceman to test and repair the solenoid circuit.
Hold the top interlock switch in, then slide the short end of the Service Switch
Actuator over the top of the interlock switch bracket and the long end over the
center of the switch plunger to hold it in.
SERVICE SWITCHACTUATOR
MEMORY PROTECTSWITCH-
BRACKET-----l
