RAISING THE PLAYFIED
.&
CAUTION
Do not raise the playfleld straight up! This game uses a slide assembly to raise and
lower the playfleld.
To raise the playfield.
1 •
Grasp bottom arch and carefully lift up playfield
only high enough to clear safety brackets. Rear
guide legs should not hit wood guide rails or
be
used
to slide out playfield.
Safely BrDsl
I---:;~~..l:::::::::_
(2used)
Rear Guide leg
(2
used)
Wood Guide Rail
(2 used)
2.
Pull the playfield out toward you until it stops
(rest position) and raise it approximately3".
Be sure playfleld Is In locked position and
does not slide back Into the cabinet. If It
does, repeat Step 2 before proceedIng to
Step 3.
3 •
Rotate playfield to upright service position (lean
on backbox) by pulling toward you and up. Listen for
the sound of a click; this insures locking and pivoting
sequence.
-
To lower the playfleld.
4 .
Rotate the playfield to the rest position. This
unlocks the pivoting mechanism.
S.
Push back playfield into cabinet and into
playing position.
Pivot Mechanism
(2 used)
DEMOLITION MAN 1·5
