Power Driver Board Continued ...
J126-1 Bled-Brown, sol 17 drive, pIayfieId ftashIamp
Jl26-2 Black-Red, sol. 18 drive, tI EM! board
Jl26-3 Black-Orange, sol. 19<iive, tI D.C MoD' Control brd
Jl26-4 Black-Yellow, sol. 20 drive, to D.C. MoIor Conlrol brd
Jl26-5 Blue-Green, sol. 21 drive, tI pIayfieId flashlamps
Jl26-6 Blue-Black, sol. 22 drive, tI playfield flashlamps
J126-7 Blue-VIOlet, sol. 23 drive, tI pIayfieId flashlamps
J126-8 Blue-Gray, sol. 24 drive,
10
pIayfieId flashlamps
J126-9
N/C
J126-10
N/C
J126-11
N/C
J126-12
N/C
J126-13
N/C
J133-1
N/C
Jl33-2
N/C
Jl33-3
N/C
Jl33-4
N/C
J133-5 N/C
J133-6 N/C
J133-7 Red-Slue, lamp row 6, not used
J133-8 Red-VIOlet, lamp row 7,
10
cabinet
J133-9 Red-Gray, lamp rON 8, to cabinet
J127·1 Brown-8lac:k, sol. 9 drive, to pIayfieId roil
J127·2 N/C
J127·3 Brown-Red, sol. 10 drive,
10
pIayfieId coil
J127 -4 Brown-orange, sol. 11 drive,
10
playfield coil
J127·5 Brown-YellCJN,sol. 12 drive, tI pIayfieId alii
J127-6 Brown-Green, sol. 13 drive,
10
pIayfieId coil
J127·7 Brawn-Blue, sol. 14 drive,
10
playfield coil
J127-8 Brown-VIOIet, sol. 15 drive, to pIayfieId cci
J127·9
N/C
J134-1 Red-Brown, lanp rON 1, tI playfield lamps
J134-2 Red-BIad(, lamp rON2,
10
playfield lamps
J134-3 N/C
J134-4 Red-Orange, lamp
rCIN
3,10
playfield lamps
J134-5 Red-YellCJN, lamp row 4, to pIayfieId lamps
J134-6 Red-Green, lamp rON 5, tI playfield lamps
J134-7 Red-8lue, lamp row 6, to pIayfieId lamps
J134-8 Red-VIOIet, lamp row 7, to playfield lamps
J134-9 Red-Gray, lamp
rCIN8,
to playfieid lamps
J128-1 N/c
J128-2 NIC
J128·3 N/c
J128-4 N/c
J128-5 N/C
Jl29-1 N/c
J129-2 N/C
Jl29-3 N/C
J129-4 N/C
Jl29-5 N/C
Jl30-1 VIOlet-Brown, sol. 1 drive,
10
pIayfieId ooiI
J130-2 VIOlet-Red, sol. 2 drive,
10
playfield coil
J130-3 N/C
J130-4 VlOIet-Clrange, sol. 3 drive, tI playfield coil
J130-5 VIOlet-Yellow, soI.4 drive,
10
playfield ooiI
Jl30-6 VIOlet-Green, sol. 5 drive, to pIayfieId coil
J130-7
N/C
J130-8 VIOIet-8lac:k,soI.7 drive, to bac:kbox coil
J130-9 N/C
J131·1 NlC
J131·2 N/C
J131-3 N/C
J131-4 N/C
J131-5
N/C
J132·1
N/C
J132·2 N/C
J132-3 N/C
J132-4 N/C
J132·5 N/C
J135-1 N/C
J135-2
N/C
J135-3 N/C
J135-4
N/C
J135-S N/C
J135-6
N/C
J135-7 N/C
J135-8
N/C
J135-9 N/C
J136-1
N/C
J136-2
N/C
J136-3 YeIaN-Gray, lamp column 8, tlcabinet
J137·1 YeIICfN-Brown, lamp c:oItmll,
tI playfield lamps
J137·2 Yellow-Red, lamp <XlIurnn2, D playfield lamps
J137-3 YeUow-Orange, lamp roIumn 3, to playfield lamps
J137-4 YeUC1N-8lac:k,lamp column 4, D playfield lamps
J137·S YelICIN-Green, lamp roIumn 5, tI playfield lamps
J137-6 Yellow-Blue, lamp column 6, D playfield lamps
J137·7 Yellow-VIOIe~ lamp column 7, Ie playfield lamps
J137-8
N/C
J137·9 Yellow-Gray, lamp column 8, to playfield lamps
J138-1
N/C
J138-2
N/C
J138-3 N/C
J138-4 N/C
J138-S
N/C
J138-6
N/C
J138-7
N/C
J138-8
N/C
J138-9
N/C
DEMOLn-ION MAN 3·34
