A-14039
Dot Matrix Controller Board
C\I
:!
J603 ~
J605-1 White, SOVAC, from normar secondary
J605-2 White, SOVAC, from xformer secondary
J605-3 Violet, 100VAC, from xformer secondary
J605-4 N/C
J605-5 Violet 100VAC, from xformer secondary
J601
2
10
20
J606
U
J601, 34-pln Ribbon Cable data, Tolfrom J202; J903; P1
J602, 26-pln Ribbon Cable data, Tolfrom J201
J603, 14-pln Ribbon Cable data, Tolfrom Dot Matrix Display/Driver
J604-1 Orange, -125V, to Display/Driver pin 1
J604-2 Blue, -113V, to Display/Driver pin 2
J604-3 N/C
J604-4 Black, ground, to Display/Driver pin 4
J604-5 Black, ground, to Display/Driver pin 5
J604-6 Gray, +5V, to Display/Driver pin 6
J604-7 Gray-Yellow, +12V, to Display/Driver pin 7
J604-8 Brown, +62V, to Display/Driver pin 8
J606-1 Black, ground, loop from J606-3
J606-2 N/C
J606-3 Black, ground, from Power Driver Brd J117-3
J606-4 Gray, +5V, loop from J606-5
J606-5 Gray, +5V, from Power Driver Brd J 117-4
J606-6 Gray-Yellow, +12V, loop from J606-7
J606-7 Gray-Yellow, +12V, from Power Driver Brd J117-2
DEMOLITION MAN 3-30
