A-17316
Flipper Opto PCB Assembly
~~
oL~
~~
oL~
8~
-
r-
r
0
SWI
0
SW2
0
GND
O.
GND
•
KEY
0
.1211DC
0
• 12VDC
-
-
-
-
'4
c..
..•
Left Side Flipper Cabinet Opto Switch Board
Jl·l
Blue-Gray from Fliptronic II Board J905·2
Jl·2
Black-Blue from Fliptronic II Board J905-5
Jl·3
N/C
Jl·4
Orange from Fliptronic II Board J905-6
Jl·5
N/C
Jl·6
Gray-Yellow from Fliptronic II Board J904-2
Jl-7
Gray-Yellow from Fliptronic II Board J904-2
J1
,----___;;uLoi;___--l2
Right Side Flipper Cabinet Opto SWitch Board
Jl·1
Black-Yellow from Fliptronic II Board J905-1
Jl·2
Blue-Violet from Fliptronic " Board J905-3
Jl·3
Orange from Fliptronic II Board J905-6
Jl·4
Orange from Left Flipper Opto Assembly J1-4
Jl·5
N/C
Jl·6
Gray-Yellow from Left Flipper Opto Assembly J1-6
Jl·7
N/C
DEMOLITION MAN 3-14
