SOLENOID/FLASHER LOCATION
CollIFlasher
111m lfQ.
Assy
No, Description
01 AE-26-1500 A-16765 Ball Release
02 AE-23-800 A-17620 Bottom Popper
03 AE-23-800 A-14525 Auto Plunger
04 AE-28-1500 A-17215 Top Popper
05 A-15943-1 A-17241 Diverter Power
06
Not Used
07 AE-23-800 B-1 0686-1 Knocker
08
Not Used
09 AE-26-1200 A-17809 Left Slingshot
10 AE-26-1200 A-17809-1 Right Slingshot
11 AE-26-1200 A-9415-2 Left Jet Bumper
12 AE-26-1200 A-H809
Top Slingshot
13 AE-26-1200 A-9415-2 Right Jet Bumper
14 AE-26-1200 A-17809 Eject
15 A-15943-1 A-H241
Diverter Hold
16
Not Used
H 24-8802
C-13337 Claw Flasher #906
24-8802
Insert Flasher #906
18 14-7993
A-H597
Elevator Motor
19 14-7992
A-16989 Claw Motor Left
20 14-7992
A-16989 Claw Motor Right
21 24-8704
A-17803 Jets Flasher #89
24-8802
Insert Flasher #906
22 24-8704
A-17983 Side Ramp Flasher #89
24-8802
Insert Flasher #906
23 24-8802
Left Ramp Upper Flshr #906
24-8802
Insert Flasher #906
24 24-8704
A-H983
Left Ramp Lower Flasher #89
24-8802
Insert Flasher #906
25 24-8704
A-17803 Car Chase Center Flshr #89
24-8802
Insert Flasher #906
26 24-8704
A-17803 Car Chase Lower Flshr #89
24-8802
Insert Flasher #906
27 24-8704
A-17983 Right Ramp Flasher #89
24-8802
Insert Flasher #906
28 24-8704
A-H983
Eject Flasher #89
24-8802
Insert Flasher #906
29
to
36
see Flipper Circuits
37 24-8704
A-17803 Car Chase Upper Flshr #89
0
38 24-8704
A-H983
Lower Rebound Flasher #89
39 24-8704
A-H803
Eyeball Flasher #89
40 24-8704
A-17983 Center Ramp Flasher #89
41 24-8802
C-13337 Elevator 2 Flasher #906
42 24-8802
C-13337 Elevator 1 Flasher #906
43 24-8802
Diverter Flasher #906
44 24-8802
Right Ramp Up Flasher #906
General illumination
01 24-6549/24-8768
02 24-6549/24-8768
03 24-6549/24-8768
04 24-6549/24-8768
05 24-6549/24-8768
"Back Panel Gol.
"Upper Right G,].
'Upper Left Go!.
'Lower Right GoI.
"Lower Left Go!.
29-30 FL-11629 A-15849-R-2 "Lower Right Flipper
31-32 FL-11629 A-15849-L -2 "Lower Left Flipper
33 SZ-33-3000
Claw Magnet
34
Not Used
35-36 FL-11630 A-14876-L
"Upper Left Flipper
"Not Shown
