A-lS205-R-4
A-1S205-l-4
Fliptronic Ii Flipper Assembly
(Lower Right)
Fliptronic II Flipper Assembly
(Lower Left)
ltqm
Part Number
De§crlptlon
1.
B-13104-R
Flipper Base Assy, Right
• B-13104-L
Flipper Base Assy, Left
2.
SW·1A·193
Switch Assembly
3_
4701-00002-00
Lockwasher,
#6
Split
4.
4105"01019-10
Sh. Metal Screw,4#,5
x
5/8
P-RH-A
5.
4008-01.079-05
Mach. Screw,
8-32'
x
5/16
H-SOe
6.
4701"00003-00
lockwasher, #8 Split
7 .
01-9375
Switch Mounting Bracket
8.
20-6516
Speednut. Tlnnerman
9.
4010-01066-06
Cap Screw, 10-32
x
3/8,
SH
10.
4701-00004-00
Lockwasher, #1Q Split
11.
A-t21 1.
1
Flipper Stop Assembly
12.
FL-15411
Flipper GOll (Orange)
a)
03-7066-5
Coil Tubing
13.
01-7695
Solenoid Bracket
14.
4006-01017-04
Mach. Screw, 6-32 x
1/4
P-RH-S
15.
10-964
Spring
Hi.
B-138B2-R
Crank Link Assembly, Right
•••
B-.13882-L
Crank link Assembly. Left
a)
B-13884-R
Ripper Crank Assembly, Right
*
B- l38~L
Flipper Crank Assembly, left
b) A-10656
Flipper link Assembly
cJ 02-4179
link Spacer Bushing
d)
401 0-01086· 14
Cap Screw, 10-32 x
7iB
SH
e) 4700-00023-00
Flatwasher, 5/8
x
13/64
x
16ga.
I)
4701-00004-00
Lod<washer#.10 Split
g} 441 0-01132-00
Nut.
i
0-32 ESN
17.
23-6577
Bumper Plug, 5tS-
18.
03-7568
Ripper·Bushing
19.
4006-01005-0S
Mach. Screw, 6·32
x
318
P-PH
2Q.
4406-01117-00
Nut, 6-32 Hex.
Associated Ports for left
&:
Right Flippers:
21.
23-£678-7
22.
20-9250·4
Flipper Rubber (Black)
Flipper
&
Shaft (Red)
Flipper Notes:
1.
•. Items for Left
Flipper Assembly
OtiLV.
2.
Each Flipper Assembly Is mounted bsnsath the
playfield, In
eenlucttcn
with the Plastic Flipper & Shaft,
and Flipper Rubber on the upper side of
the
playfili[ild,
3.
With
the flipper. in 1he non-activated position,
the E.O.S. swheh contacts must have a gap of
.06.2 (±.Ci5) inch. When fltpper is activated switch
must dose.
4.
Any. adjustment of the E.O.S. Switch must be made
at a minimum distance of
0.25
inch from the switch
body.
5.
longer blade of E.O.S. Switch must be straight.
Gap adjustment Is done by adjusting shorter
blade.
6_
All moving elemants of the assembly musl operate
freely without
any
evidence
of
binding.
7, Apply Loctite
1M
242 when rsatachlnq screws to the
Flipper Slop Assembly, the Solenoid Brackel, and the
FUpp'ar Bushing.
•
•
:mtarula 2-20
