7 ..Unlock and open the coin door. Move the molding latch lever toward the leU side of the game. UII the
front molding off the playl'ield cover glass return the latch lever toward the righi, and close the coin door.
Carefully slide Ihe glass downward,
untll
it
clears.
the
grooves 01 the lelt and right side moldings.
LiJllhe
_glass up and away from the
game.
8. Place a level or an lnctinornster-cn the prayfJeJd surface. Adjust the leg levelers for proper ptayfield level
(side-to-side).
NOTE:
II is
recommended
that this measurement be made ON the playlield, not the
cabinet nor Ihe playfield cover glass. Tighten the nut on each leg leveler shaft to maintain this setting ..
9.
The TRU-PITCHTM
level
lslccated
on the
shooter
rail. This
allows
the
operator
to
accurately
pitch
the
game - WITHOUT REMOVING
TI'{E
GLASS'~ wtiBn
it
[s first set in a new location. The first Hneon the level
is
approximately 6 degrees.
Every line
after that
is approximately another
1/2
degree
of
Pitch.
w.~
recommend you pilCh the game wil-h the NOSE of the bUbble
between the
first and second nne on
the
level
(between 6
and
6-1/2
degrees).
!
IMPORTANT
Playtield pitch angle can alfect the
operation of
the plumb bob
tnt.
The.
plumb
bob weight
Is
among the
parts
In
Ihe cash box:
the
operator
shol:lld
lnstan
the welg'hl and
adjllst
this Illt
mechanism
for
proper
operation, after completion of Ihe desired playtieJd pitch 8F1gle settin§'j. The unit is tactery installed lor a 6~
1/2
degree angle. If an adjustment
IS
necessary, loosen the screw at the bottom of the
unit.
Move Ihe
pointer,
one grove at a tlrne to Ihe
left or
the
right~
depending
on
fhe degree. desired. Ho.ld
the
polnter
In
place and tighten screw.
10, Nlove Ihe
game
lnto the
desired
tocatton: recheck lhe level and pitch
angle
ofth,e'playlleld.
11. Be
sure the
requIred numoer
o;
ball are installed.
,fl!Jt'8c'Ula
uses
four
balls.
12: Instal playneld rnylars
if
desired.
NOTE:
The
"iltat'lt18
playfieJd is coated with a special hardcoat
surface and does not require a protective mylar. However,
my!ars can be purchased thr0ugh your local
WlIIiams Distributor.
Specify
part
number 03-S860-1 for fiJll playtield
mylar.
13.
Clean and
rei
ns1all the playfield cover glass, Prepare Ih,e game 19r player operation.
14. To attach the line cord, remove the envelope stapled to the inside o,f the- cabinet (near the cashbox).
Remove the four Philllps~head screws that moun! to tine cord cover plate to the rear cabinet.
Match Ihe
pronqs
on
the plug with the holes in the receptacle, and push the line cord securely into place. Make' sure
the
cord
is alignect.with the indernation on the cover plate (indentation snoulo point toward bottom of the
cabine1). Remount line cord cover plate. 'If desired, four tamper reslstant screws have been provided in an
enevlope marked "Security Screws~ (located in the cashbox] to remount
cover
plate.
tpart of cabinet shown
for r~ference only )
Receptacle
