You can check strobe and select lines with a logic probe.
During Gameplay Mode, the select and strobe lines should
pulse. Test for this pulse at connector SIJ3, pins 1 through
8 and 10. You should find the same pulsing at connector
SIJ1, pins 3 through 10 and 13. If not, either U1 or U2 may
be bad. Before replacing these ICs, check or replace C1, a
one microfarad electrolytic capacitor.
•
•
•
HEAVILY DISTORTED SOUND
Check the negative 12-volt regulator on the Sound Interface
Board. The error amplifier and series-pass device for this
analog regulator reside in chip U3. The circuit also con-
tains two, ten and 100 microfarad electrolytic capacitors.
These tend to fail before the regulator chip. As a rule of
thumb, larger electrolytics fail before smaller ones.
•
•
Check the voltage across the 100 microfarad capacitor.
You can also take this measurement between SIJ2, pin 3
and ground (pin 5). During your test, the Sound Interface
Board should be connected to the Sound Board.
You should find -12 volts DC and not more than 12 millivolts
•.
of AC ripple.
Check for the ripple with the
AC
setting on
your voltmeter.
If you find excessive ripple, change the 100
microfarad capacitor and recheck the circuit.
••
•
4-28
