Drop Target Lubricants
•
Step No.
Lubricant
Component Location
1
Oil
In the hole of each snap-in coil nyliner
2
Oil
Around the surface of each pivot pin
3
Grease
In the pivot hole of each drop target link
4
Grease
In each slot of the stationary bottom plate
5
Grease
In each slot of the backplate
.Medium viscosity oil
.sUNEX
#257,
WAYOIL
.Viscosity: 300-350
.MBllnstrument
Grease
.Non-Gumming Lubricant
•
CLEANING THE PLAYFIELD
The
BALL Y
playfield has an improved "tuff-coat" finish with
excellent wearing properties. Playfield life expectancy and
play appeal can be extended by periodic cleaning.
DO...
Clean the playfield with
WILDCAT
#125 compound.
(WILDCAT CHEMICAL COMPANY,
1349 East Seminary
Drive, Fort Worth, TX 76115,817-924-8321).
Wildcat #125
compound is a combination cleaner and polish. Factory en-
gineers have tested this product, and found it to be very ef-
fective. If
WILDCAT
#125 compound is unavailable, ask
your distributor to order it.
Inspect and hand polish the balls in a clean cloth. Replace
chipped balls. Otherwise these balls will ruin playfield finish
in a short time.
•
DON'T .•.
Don't use quantities of water, caustic or abrasive cleaners or
cleaning pads on the playfield. Don't allow a wax or polish
bUild-up. Waxes yellow with age and spoil play appeal.
3-5
