DETACHING THE BACKBOX
Before detaching the backbox assembly from the game, fol-
low this procedure ...
•
NOTICE
Before disconnecting printed circuit board connectors, turn
off game power.
.
•
[ ] 1.Unlock and remove the backbox glass.
[ ] 2.Disconnect the front cabinet and playfield cable connec-
tors from backbox PC boards. Push the cables and their
tube down into the cabinet.
•
[ ] 3. Remove two 3/8-inch bolts and washers that secure the
backbox to the front cabinet.
[ ] 4.Disengage the backbox safety latch on the back of the
cabinet. Lower the backbox to its transport position.
•
[ ] 5.Remove four hinge nuts that fasten the backbox hinges
to the front cabinet's neck.
[ ] 6. Remove the ground braid that runs between the back-
box and the front cabinet.
[ ] 7.Pull or slide the backbox toward either side of the front
cabinet. Lift the backbox off the cabinet. Because the back-
box is large, lifting it is easier if an associate helps.
To attach
a
backbox to the front cabinet, follow steps 1
through
7
in reverse.
;;
SWITCH ASSEMBLY ADJUSTMENTS
Switch assemblies consist of switch blades, contact
separators, plastic tubing and mounting screws. Before at-
tempting to adjust a switch assembly, be sure that screws
are tight. If not, tighten the front screw (near the switch
blade) first. Then tighten the back screw (near the soldered
3-2
••
•
