BRIGHT LIGHT FUSE BOARD. The Bright Ught Fuse
•
Board is part number A080-91901-BOOO.
This board
includes 16 fuses. The fuses protect SCRs in the phase C and
phase 0 lamp drive circuits.
BOARDS NOT IN THE BACKBOX
There are three relay boards installed in the game to
control various lamp circuitry. One controls the red-sleeved
Gis and another the remaining playfield Gis. These two
boards are located right on the underside of the playfield.
The last relay board is located on the Insert Panel and
controls the panel lights.
"
"
CONTROL LOCATIONS
THE ON-OFF SWITCH is on the bottom of the cabinet, near
the right, front leg.
THE VOLUME CONTROL is inside the coin door. Look at
the left, inner wall of the cabinet, on the tilt mechanism
board.
•
THE CREDIT BUTTON is left of the coin door on the front
of the cabinet.
GAME ADJUSTMENT/DIAGNOSTIC SWITCHES. The
SELF TEST button switch is inside the coin door. This
switch assists you during game adjustments, bookkeeping,
and problem diagnosis. Details appear in Chapter 2.
•
INSTALLATION PROCEDURE
[] 1.0pen the shipping container. Remove cartons, parts
and other items. Set them aside.
-.
[ ] 2.Leg levellers and bolts are provided in the cashbox. In-
stall levellers on the game's rear legs. Set the game on a
flat surface or dolly. Bolt the rear legs to the game.
•
1-4
